Web-based central management of your EtherWAN network
Network topology discovery and visualization of physical connections
Automated firmware upgrade scheduling
Perform bulk configuration deployment for multi-devices
特長
概要
機能
仕様
製品型番
動画
無料デモ
Web-based graphical user interface
Works with any modern browser without the need for a plug-in
Automated network discovery and topology visualization
Device configuration via SNMP, Web, Telnet, and SSH
Simplified and rapid IP address assignment to devices
Event handling via polling and SNMP traps
Notifications sent-out via email, SNMP trap, SMS, and push notifications via eVue Mobile app
eVue is network management software for EtherWAN's managed devices, designed to simplify network configuration. It provides the ability to discover EtherWAN devices on a network and display an intuitive, visual representation of the network topology. Plus, it allows system administrators to monitor network status, manage and perform bulk configuration deployment, schedule firmware upgrade, and more. eVue gives you up to the minute information on critical network systems with the user-defined event notifications. Faster and easier switch deployment and management means eVue will save you serious time, effort, and money.
EtherWAN — "When Connectivity is Crucial."
Automated Network Discovery
- Discovers EtherWAN devices on the network
- Topology visualization lets you see your entire network
- Discover devices across multiple subnets
Event Management & Notification
- Notifications based on multiple events (Node Up/Node Down, Service Up/Service Down, SNMP traps, etc.)
- Tiered event severity levels (Critical, Major, Warning, Indeterminate, Normal, and Cleared)
- Easily set up notification alarms and alerts through SMS, email, SNMP trap, and push notifications via the eVue mobile app
- Event recording with export capability
Network Configuration
- Rapidly allocate IP addresses, subnets, and default gateways to multiple devices on one screen
- Change configurations for multiple devices simultaneously
- Command line interface for easy remote access to devices
- Fast deployment with efficient backup and restoration of device configurations
- Multi-device firmware upgrade capability
- Schedule firmware upgrades to minimize the impact of downtime
Availability Monitoring
- Quickly detect and display Panel LED, VLAN and PoE configuration status
- Group devices by configurable categories for easy management
Mobile App
- Simple network management with a mobile device
- Change IP configuration remotely
- Receive push notifications
- View network status instantly
- View event history
eVue Server
| CPU | Intel i5 2.5GHz and above |
| RAM | 4GB and above |
| Hard Disk | 1TB, 7200 RPM, SATA-3Gb/s or higher |
| Operating System | Windows 7 (64-Bit), Windows 10 (64-Bit) |
| Browser | Internet Explorer 11, Microsoft Edge, Chrome v64 or later, Firefox v58 or later, Safari 11.11.1 or later |
eVue Mobile Apps
| iOS version | 13 and above |
| eVue server version | v4.01.13 and above |
Supported EtherWAN Devices
| Ethernet Switches | Firmware Version |
| EG97000 Series | v3.00.0 |
| EG99000 Series | v3.04.4.1 |
| EX89000 Series | v1.94.6.3 |
| EX87000 Series | v1.94.6.3 or v4.00.0 |
| EX83304 Series | v2.02.7.1 |
| EX83000 Series | v1.94.6.3 |
| EX78900X Series | v5.00.3.3 |
| EX78900E Series | v5.00.2.1 |
| EX78900 Series | v2.02.1 |
| EX78162 Series | v1.94.6.3 |
| EX78000 Series | v1.94.6.3 or v4.01.0 |
| EX77964 Series | v2.02.1 |
| EX77900 Series | v2.02.1 |
| EX77000 Series | v1.94.6.3 or v4.00.0 |
| EX76000 Series | v1.94.6.3 |
| EX75900 Series | v5.00.2.1 |
| EX75000 Series | v1.94.6.3 |
| EX73900E Series | v5.00.2.1 |
| EX73900 Series | v2.02.1 |
| EX73000 Series | v1.94.6.3 or v4.01.0 |
| EX71000 Series | v1.94.6.3 or v4.01.0 |
| EX70900 Series | v1.94.6.3 |
| EX63000 Series | v1.94.6.3 or v4.01.0 |
| EX61000A Series | v1.94.6.3 or v4.01.0 |
| EX29000 Series | v1.94.6.3 |
| EX27000 Series | v1.94.6.3 or v4.01.0 |
| EX26484* (Only sold in U.S. and Canada) | v8.40.1589 |
| EX26262F Series* | v6.54.2570 |
| EX25611* | v3.60 |
| SmartE Series* | v3.0 |
| Wireless | Firmware Version |
| EW200 Series* (Not sold in U.S. and Canada) | 0EW00G0.I51_e51.0EW0_05241200 |
| EW50 Series* (Not sold in U.S. and Canada) | 0EW0Y80.I51_e51.0EW0_05251700 |
| Ethernet Extender | Firmware Version |
| ED3575* | v1.94.3.13 or v4.02.1.3 |
* Status monitoring only and limited function support.
Note: eVue supports the listed firmware versions and higher.
Gain broader monitoring of your industrial network
Efficient network management is more important than ever. Manage all of your EtherWAN devices with an eVue license, with full functionality. Contact us to discuss your project today.
Step 1.
Make your account secure and safe based on eVue designed security settings
Step 2.
Simplify network management
Step 3.
Visual network monitoring
Step 4.
Efficient event management
Step 5.
Flexible alerting on critical issues
Try the eVue software
Evaluate the ease-of-use of eVue by downloading the software below and activating the demo.
- • Install the software on your Windows computer
- • Manage up to 16 nodes with your demo, fully functional with all features included
- • Access the interface via any modern web browser, plug-in free!
To activate the demo, log in initially with the default credentials. When the Validate License window is displayed, simply click on the Demo button.
